Trek Domane AL 4 Gen 5

The Trek Domane AL 4 Gen 5 is an endurance-focused road bike built for riders who want a comfortable, capable, and versatile machine for everything from daily fitness rides to long-distance adventures. Featuring a lightweight 100 Series Alpha Aluminium frame, a vibration-damping carbon fork, and Shimano Tiagra components, the Domane AL 4 delivers smooth performance and confident handling on a wide variety of road surfaces.

Designed with Trek's proven endurance geometry, the Domane AL 4 helps reduce rider fatigue on longer rides while maintaining responsive handling and efficient power transfer. Wide tyre clearance, hydraulic disc brakes, and integrated mounting points make it equally at home on rough roads, commuting routes, and light gravel adventures.

Key Features

• Lightweight 100 Series Alpha Aluminium frame
• Domane AL full carbon fork for improved comfort and handling
• Shimano Tiagra 2x11-speed drivetrain
• Hydraulic disc brakes for confident all-weather stopping power
• Bontrager Paradigm Tubeless Ready wheelset
• Bontrager Kwaremont Comp 700x32c tyres
• Internal cable routing for a clean appearance
• Mudguard compatibility for year-round riding
• Integrated top tube bag mounts for adventure riding
• Endurance geometry designed for all-day comfort
• Maximum system weight: 125 kg
• Weight: 10.10 kg (Size 56)

Frameset

• Frame: 100 Series Alpha Aluminium, internal cable routing, flat-mount disc brake mounts, UDH, 142x12mm thru axle
• Fork: Domane AL Carbon Fork, tapered steerer, flat-mount disc brake mounts, 12x100mm thru axle

Drivetrain

• Shifters: Shimano Tiagra R4020
• Front Derailleur: Shimano Tiagra R4000
• Rear Derailleur: Shimano Tiagra
• Crankset: Shimano Tiagra R4000, 50/34T
• Bottom Bracket: Shimano RS501 BSA
• Cassette: Shimano RS400, 11-36T
• Chain: Shimano LG500
• Drivetrain: 2x11-Speed

Brakes

• Brake System: Shimano Hydraulic Disc Brakes
• Brake Rotors: Shimano RT66, 160mm Front & Rear

Wheels & Tyres

• Wheelset: Bontrager Paradigm 23 Tubeless Ready
• Front Hub: Formula RX-512, 12x100mm
• Rear Hub: Formula RX-142, Shimano 11-Speed Freehub, 12x142mm
• Tyres: Bontrager Kwaremont Comp, 700x32c

Components

• Saddle: Verse Short Comp, 145mm
• Seatpost: Bontrager Comp Alloy, 27.2mm
• Handlebar: Bontrager Comp Alloy
• Stem: Bontrager Elite Blendr Compatible
• Bar Tape: Trek Gel Cork

Designed For

• Endurance Road Riding
• Long Distance Cycling
• Fitness and Training Rides
• Fast Group Rides
• Commuting
• Light Gravel Adventures
• Weekend Touring
