Revolt 2 - Asphalt Green

Confident handling

Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.

Tuned compliance

Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tires up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.

• Sizes
  S,L
• Colours
  Asphalt Green,Storm Cloud
• Frame Material
  ALUXX Grade Aluminum,flat mount disc,12x142mm thru-axle Flip chip Drop out
• Tire
  Giant CrossCut AT 2 Tubeless, 700x38C
• Tire Size
  700x53mm at long RC
• Tire Size - Measuring Unit
  MM
• Fork
  Advanced-Grade Composite, Full-Composite OverDrive one Steerer, 12x100mm thru-axle, flat mount disc
• Stem
  Giant Sport
• Headset
  Giant Sport
• Front Derailleur
  Shimano Sora
• Handlebar
  Giant Connect XR Ergo-Control, 31.8mm
• Seatpost
  Giant D-Fuse Alloy (AD614) Offset 14mm
• Shifters
  Shimano Sora, 2x9
• Rear Derailleur
  Shimano Sora, long cage
• Grip
  cork tape with gel
• Crankset
  FSA Vero Pro, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
• Saddle
  Giant Approach
• Pedals
  GA,Pan-Eu: no pedal, GU,GV:Platform pedal Rest GSC :Pedal w/Toe clip and strape
• Brakes
  Tektro MD-C550 mechanical, Giant MPH rotors [F]160mm, [R]160mm
• Hubs
  Giant alloy, 12mm thru-axle
• Cassette
  CH-HG400, 11x34
• Brake levers
  Shimano Sora
• Spoke
  stainless
• Chain
  KMC X9 with Missing Link
• Rims
  Giant S-X2 Disc wheelset, alloy
• Bottom Bracket
  cartridge

*All specifications and prices listed are subject to change without notice.
