Key features
- Need to get around town but aren’t looking to do it on a skinny race bike? The Sub Cross 20 is the fun-loving, easy-going, commuter-friendly companion you’ve been waiting for. Designed to maximize comfort, stability, and convenience during rides around the city, the Sub Cross 10 is the natural bike of choice to tour or commute whether you’re in vacation mode or a 9–5er turning pedals toward the weekend.
Frame & Fork
| Frame |
Sub Cross Alloy 6061, Custom Butted Tubing, Internal Cable Routing, Sub Cross Men / Lady Geometry |
| Fork |
SR Suntour NEX, 63mm Travel |
Drivetrain
| Rear Derailleur |
Shimano CUES RD-U6000-SGS, Shadow Type, 11-Speed |
| Shifters |
Shimano CUES SL-U6000-11, 2-Way Release |
| Crankset |
Prowheel C10Y-NW Steel, 36T |
| Bottom Bracket |
Feimin FP.B908N, BB73, Square Taper |
| Chain |
Shimano CN-LG500 |
| Cassette |
Shimano CUES CS-LG400-11, 11–50T |
Brakes
| Brake System |
Tektro HDM275 Hydraulic Disc Brakes |
| Rotors |
Tektro, 6-Bolt, 160mm Front / 160mm Rear |
Cockpit & Seating
| Handlebar |
HL MTB-AL-312BT, 720mm Width, 12mm Rise, Black
Syncros Comfort Lock-On Grips |
| Stem |
HL TDS-C342-8FOV, 10°, 31.8mm, Black |
| Seatpost |
HL SP C212, 31.6mm × 350mm, Black |
| Saddle |
Syncros Capilano Sport |
| Headset |
Syncros OE Press Fit, 1 1/8", OD 50mm / ID 44mm |
Wheels & Tires
| Rims |
Alexrims X-20 Disc, 32H, Black |
| Front Hub |
Formula DC-19 FQR Disc |
| Rear Hub |
Formula DC-25 8-Speed RQR Disc |
| Spokes |
14G Stainless Steel, Black |
| Front Tire |
Kenda Booster, 700×45C, 30 TPI |
| Rear Tire |
Kenda Booster, 700×45C, 30 TPI |
Additional Information
| Approx. Weight |
13.63 kg / 30.05 lbs (Without Pedals) |
| Max System Weight |
130 kg (Bike + Rider + Equipment + Additional Luggage) |
Please note: Specifications are subject to change without prior notice.
